Building My First Cisco Interface Health Check Automation

Learning automation

From a manual interface check to a repeatable Python workflow.

Network automation can sound complicated at the beginning. My approach is to start with a small, practical script that solves a real operational task and helps me understand every step.

This article walks through my first Cisco interface health check script. It connects to a Cisco IOS device, collects interface information, compares the current state with the previous run, and creates a simple health report.

Why this is useful

In daily network operations, interface status is one of the first things engineers check. A quick interface view can answer basic but important questions:

• Is an interface up or down?
• Has an interface changed since the last check?
• Was a new interface added?
• Was an interface removed?
• Did the IP address, status, or protocol state change?

Manually checking this is useful for learning, but automation helps make the check repeatable. This script creates a baseline on the first run and then compares later output against that saved state.

Cisco DevNet Sandbox

Learning automation without owning Cisco hardware

One reason this type of automation is easier to start today is Cisco DevNet Sandbox. Engineers do not always need physical Cisco hardware at home to practise basic automation workflows.

Cisco provides hosted sandbox environments that can be used for learning, testing, training, API practice, and small development projects. Some environments are Always-On, which makes them useful for quick practice sessions when the goal is to understand how tools like Python, Netmiko, RESTCONF, NETCONF, and IOS XE interact with network devices.

Tools and setup

The script uses Python, Netmiko, python-dotenv, and TextFSM templates. Device details are loaded from environment variables rather than being written directly into the script.

netmiko
python-dotenv
ntc-templates

NETMIKO_HOST=devnetsandboxiosxec8k.cisco.com
NETMIKO_USERNAME=your_username
NETMIKO_PASSWORD=your_password
NETMIKO_PORT=22
NETMIKO_DEVICE_TYPE=cisco_ios

Keeping credentials outside the script is an important habit. Real usernames, passwords, tokens, and sandbox credentials should not be uploaded to GitHub.

Baseline and change detection

The core idea is simple: save the latest interface state, then compare the next run against the previous saved output.

try:
    with open(latest_file_path, 'r') as file:
        previous_state = file.read()
except FileNotFoundError:
    previous_state = None

if previous_state is None:
    change_status = 'BASELINE CREATED'
elif previous_state != latest_state:
    change_status = 'CHANGE DETECTED'
else:
    change_status = 'NO CHANGE TO PREVIOUS FILE'

On the first run, the script creates the baseline. On later runs, it can identify whether the interface output changed and then record the result in a change log.

Report output

The script creates a report file inside the reports folder. The filename includes a timestamp so every run can produce separate evidence.

The report includes the date, hostname, device information, active interfaces, inactive interfaces, detected changes, and simple statistics.

====================
INTERFACE HEALTH REPORT
====================
Date: 2026-09-04 10:30:00
Hostname: Router1

====================
Active Interfaces: [...]
Inactive Interfaces: [...]

====================
CHANGES SECTION:
No detailed interface changes observed.

====================
STATISTICS
Active interfaces: 5
Inactive interfaces: 2
Health interfaces: 71.43%.

Full script

The full learning script is included below. The latest project files are also available in my GitHub repository.

"""
Cisco Interface Health Check

This script connects to a Cisco IOS device using Netmiko,
collects interface status, compares it with the previous run,
and creates a simple health report.
"""

from netmiko import ConnectHandler
import os
from datetime import datetime
from dotenv import load_dotenv

load_dotenv()


def get_device_config():
    device = {
        'device_type': 'cisco_ios',
        'host': os.getenv('NETMIKO_HOST'),
        'username': os.getenv('NETMIKO_USERNAME'),
        'password': os.getenv('NETMIKO_PASSWORD'),
        'port': int(os.getenv('NETMIKO_PORT', 22))
        }
    return device

def connect_to_device(device):
        """ Create a Netmiko SSH connection to the network device """

        return ConnectHandler(**device)

def save_text_file(file_path, content, mode='w'):
    """ Save a text content to a file. """

    with open(file_path, mode) as file:
        file.write(content)




def main():
        # current script logic

    device = get_device_config()
    connection = connect_to_device(device)

    if not device['host'] or not device['username'] or not device['password']:
        raise ValueError("Missing device connection details. Please set NETMIKO_HOST, NETMIKO_PASSWORD and NETMIKO_USERNAME")


    current_time = datetime.now().strftime('%Y-%m-%d %H:%M:%S')
    file_time = datetime.now().strftime('%Y-%m-%d_%H-%M-%S')
    os.makedirs('reports', exist_ok=True)
    os.makedirs('logs', exist_ok=True)
    report_filename = os.path.join('reports', f'interface_health_report_{file_time}.txt')
    latest_file_path = os.path.join('logs', 'latest_interface_state.txt')
    log_file_path = os.path.join('logs', 'change_log.txt')


    interfaces = connection.send_command('show ip int brief', use_textfsm=True)
    version = connection.send_command('show version | incl Processor board ID')
    hostname_output = connection.send_command('show running | incl hostname')
    hostname_part = hostname_output.split()
    hostname = hostname_part[1]



    latest_state = connection.send_command('show ip int brief')
    change_status = ''

    # compare previous and current state
    def parse_interface_state(interface_text):
        '''
            withdraw information from latest state (raw variable), translate to lines, read from lines to the dictionary, grouping it

        '''
        interface_dict = {}

        lines = interface_text.splitlines()

        # starting from the second line in the block
        for line in lines[1:]:
            single_line = line.split()

            if len(single_line) >= 6:
                interface_name = single_line[0]
                ip_address = single_line[1]
                status = single_line[4]
                protocol = single_line[5]

                # condition for administratively down, status and protocol variables must be updated
                if single_line[5] == 'administratively':
                    status = 'administratively down'
                    protocol = single_line[6]

                interface_dict[interface_name] = {
                    'ip_address': ip_address,
                    'status': status,
                    'protocol': protocol
                }

        return interface_dict


    try:
        with open(latest_file_path, 'r') as file:
            previous_state = file.read()
    except FileNotFoundError:
        previous_state = None

    if previous_state is None:
        change_status = 'BASELINE CREATED'
        print('Baseline created.')
    elif previous_state != latest_state:
        print('Change detected - investigation required')
        change_status = 'CHANGE DETECTED'
    else:
        change_status = 'NO CHANGE TO PREVIOUS FILE'
        print('No change to previous file.')



    observed_changes = []



    if previous_state is not None:
        previous_interfaces = parse_interface_state(previous_state)
        current_interfaces = parse_interface_state(latest_state)


        for interface in current_interfaces:
            if interface not in previous_interfaces:
                observed_changes.append(f"ADDED: {interface} with IP {current_interfaces[interface]['ip_address']}")
                observed_changes.append(f"Status: {current_interfaces[interface]['status']}")
                observed_changes.append(f"Protocol: {current_interfaces[interface]['protocol']}")

        for interface in previous_interfaces:
            if interface not in current_interfaces:
                observed_changes.append(f"REMOVED: {interface} was previously IP {previous_interfaces[interface]['ip_address']}")
                observed_changes.append(f"Status: {previous_interfaces[interface]['status']}")
                observed_changes.append(f"Protocol: {previous_interfaces[interface]['protocol']}")

        for interface in current_interfaces:
            if interface in previous_interfaces:
                old = previous_interfaces[interface]
                new = current_interfaces[interface]

                if old['ip_address'] != new['ip_address']:
                    observed_changes.append(
                        f"CHANGED: {interface} IP changed from {old['ip_address']} to {new['ip_address']}"
                    )

                if old['status'] != new['status']:
                    observed_changes.append(
                        f"CHANGED: {interface} status changed from {old['status']} to {new['status']}"
                    )

                if old['protocol'] != new['protocol']:
                    observed_changes.append(
                        f"CHANGED: {interface} protocol changed from {old['protocol']} to {new['protocol']}"
                    )





    save_text_file(latest_file_path,latest_state)
    save_text_file(log_file_path, f'{current_time} - {change_status} on {hostname}  - show ip int brief\n', mode='a' )



    active_int = []
    inactive_int = []
    # count  interfaces
    for interface in interfaces:
        if interface['status'] == 'up' and interface['proto'] == 'up':
            active_int.append(interface['interface'])
        else:
            inactive_int.append(interface['interface'])



    active_count = len(active_int)
    inactive_count = len(inactive_int)
    total_int = len(interfaces)
    health_interfaces_status = round(active_count / total_int * 100, 2)

    if inactive_int == []:
        inactive_int = 'INACTIVE INTERFACES NOT DETECTED.'
        inactive_count = 0


    report_lines = []
    report_lines.append(20 * '=')
    report_lines.append('INTERFACE HEALTH REPORT')
    report_lines.append(20 * '=')
    report_lines.append(f'Date: {current_time}')
    report_lines.append(version) # device version
    report_lines.append(f'Hostname: {hostname}') # device version
    report_lines.append('\n')
    report_lines.append(20 * '=')
    report_lines.append(f'Active Interfaces: {active_int}')
    report_lines.append(f'Inactive Interfaces: {inactive_int}')
    report_lines.append('\n')
    report_lines.append(20 * '=')
    report_lines.append("CHANGES SECTION:")

    if observed_changes:
        for change in observed_changes:
            report_lines.append(change)
    else:
        report_lines.append("No detailed interface changes observed.")

    report_lines.append("")
    report_lines.append(20 * '=')
    report_lines.append('STATISTICS')
    report_lines.append(f'Active interfaces: {active_count}')
    report_lines.append(f' Inactive interfaces: {inactive_count}')
    report_lines.append(f'Health interfaces: {health_interfaces_status}%.')
    report_lines.append('\n')


    report = '\n'.join(report_lines)



    with open(report_filename, 'w') as file:
        file.write(report)

    print(report)


    connection.disconnect()



if __name__=="__main__":
    main()

What I learned and next improvements

This script helped me understand how Python can connect to a real network device, run show commands, store command output, create a baseline, compare later runs, and generate a basic report.

The most important lesson is that automation does not need to start as a large, complex platform. A small script that checks one operational area can already create useful evidence and build confidence.
